Residential construction

OBO solutions for residential construction:

• OKB brush bar trunking system: The OKB system stands for invisible device installation and discreet cable routing. Wherever it is installed, there is almost no sign of how the room is supplied with power. Only a slender, discreet brush bar offers a clue. The special feature: Along its entire length, the trunking has an opening to the wall, which is covered by the brush bar, ensuring a discreet supply to the room.
• GES R2 round floor socket: The small, round GES R2 floor socket supplies data and power to exactly where they are needed. Its handling is simple and uncomplicated: The connection cables are inserted in the compact installation space, which is then closed off with a cover. With regard to the cover: Here, a total of 8 different variants are available.
• UDHOME2 floor socket: Small with an impressive interior: This is the UDHOME2 floor socket. With dimensions of just 140 mm x 140 mm, two sockets and data connections can be housed here. This is achieved by the interior space, which is slanted at an angle of 54 degrees.
• RAUDUO electrical and heating trunking: The RAUDUO combined electrical and heating trunking is the risk-free renovation idea for the standardised routing of the electrical and heating lines in shared skirting trunking. Thanks to the ingenious 2-in-1 solution, heating pipes and electrical cables are routed simply in a shared trunking base. The trunking cover of the system is available with a sealing lip for existing buildings with a lip width of 6 mm and also with a tapering lip end.
• Concealedand cavity wall boxes: The OBO flush-mounted and cavity wall boxes use numerous clever product details to set new standards for quality and speed on any construction site. They are manufactured from 100% halogen-free material and, if there is a fire, effectively prevent the release of toxic halogens. In the sustainable production of the concealed sockets, we use high-quality recycled materials, with 80% being made from recycled material. The tested and certified noise protection of the airtight cavity wall sockets offers more peace and quiet.
• Quick pipe system: The Quick pipe system connects the benefits of cable trunking and standard electrical installation pipes in an intelligent system for surface installations. It comprises the Quick pipe electrical installation pipes, the Quick clips and a selection of perfectly matched fittings. The system is ideally suited for installations on walls and ceilings in indoor and outdoor areas. For example, in residential buildings, it will be located in the cellar.
• Junction boxes: OBO offers a wide range of junction boxes, using which any installation challenge can be tackled. Naturally, this also applies to residential construction. Here, it is primarily the everyday heroes of the A series which offer reliable solutions for attics and cellars, private garages and carports, or for roller blind boxes. The A series junction boxes are made of halogen-free, thermoplastic plastics and offer simple solutions for simple applications. Thanks to the external fastening and clamshell lid, they can be fastened quickly and in an uncomplicated manner.
