165 MBG... roof cable holder for flat roofs, with increased base section

Item no. 5218716 | EAN 4012196648320

5218716 / 165 MBG-8-10 200
200 mm
Rd 8-10 mm
Product description
Product description
• Closed form with base

• With double conductor holder

• Filling weight 1 kg (frost-resistant concrete)

• Sleeve from polyethylene, black, UV-resistant and weatherproof

• Base made of polypropylene, black, UV-resistant and weather-resistant

• With larger base section (Ø 200 mm) for better stability
Technical data

Technical data

Application Flat roof
Colour Black
Conductor diameter, max. 10
Conductor diameter, min. 8
Conductor fastening type With clip
CO₂ Footprint (GWP) Cradle-to-Gate 0,654 kg CO₂e / 1 Piece
Dimension 8-10mm
Fit Rd 8-10 mm
Length 200 mm
Material Polyamide/Polyethylene
Mounting type Miscellaneous
All types

All types

Types Length Fit Item no. Quantity SSU
165 MBG-8-10 200 200 mm Rd 8-10 mm 5218716
12 piece
Accessories

System accessories

Products Types Item no. Quantity SSU
Universal flat conductor adapter for roof conductor holder, type 165/MBG Universal flat conductor adapter for roof conductor holder, type 165/MBG 165 MBG UH 5218882
25 piece
Flat conductor adapter for roof conductor holder, type 165/MBG Flat conductor adapter for roof conductor holder, type 165/MBG 165 MBG HFL 5218885
60 piece
Mesh cable tray adapter for roof conductor holder Mesh cable tray adapter for roof conductor holder 165 MBG HGRM 5218886
50 piece
