Base, MultiBase with acoustic signalling
Item no. 5096421 | EAN 4012195393917
- Product description
-
Product description
• Suitable for V 25-B+C, V 20-C and V 10-C
• With remote signalling, potential-free changeover contact, for function monitoring
• With acoustic signalling for function monitoring, signal tone can be shut down for 24 h
• Pre-mounted and ready for connection
-
- Technical data
-
Technical data
Conductor cross-section, rigid (single-wire/multiwire), max. 35 mm² Conductor cross-section, rigid (single-wire/multiwire), min. 2,5 mm² Dimension 3-polig Installation type DIN rail 35 mm Network form Other Operating temperature, max. 80 °C Operating temperature, min. -40 °C Pole version 3 Protection rating IP20 Remote signalling yes Signalling on device Optical and acoustic Version for 3-pole with AS; base - All types
- Downloads
-
Data sheet V20-C U-3 AS / 5096421 , 0.25MB , pdf
