Cable ladder with Z rung, light-duty A4 3000 | 600 | 3 | no

Cable ladder with Z rung, light-duty A4

Item no. 7098094 | EAN 4012195708025

Item no. / Types

Length	3000 mm

Width

Rail thickness	3 mm

Maintain electrical functions	no

Product description

Product description

Light-duty shipbuilding cable ladder with perforated side rail of side height 35 mm with welded, perforated Z rungs. Load tested according to IEC in conjunction with connector, type SLV.

Technical data

Technical data

Dimension	35x600
Dimension	35x606x3000
Dimension B	606 mm
Fastening of rung	Welded
Height	35 mm
Length	3000 ft
Length	3000 mm
Maintain electrical functions	no
Material	Stainless steel
Rail thickness	3 mm
Rung distance	300 mm
Rustproof steel, pickled	yes

Side perforation	yes
Side rail version	Flat profile
Support spacing 1.0 m	2,2 kN/m
Support spacing 1.5 m	1 kN/m
Support spacing 2.0 m	0,55 kN/m
Support spacing 2.5 m	0,25 kN/m
Support spacing 3.0 m	0,25 kN/m
Surface	Bright, treated
Version of the rungs	Profile perforated
Wide-span version	no
Width	600 mm

Technical data

Load diagram, cable ladder, type SLZ L A4

Permitted cable tray/ladder load in kN/m without man load
Support width in m
Rail bend in mm at permitted kN/m
Load curve with cable tray/ladder width in mm
Strut bend curve according to support width
Load scheme during testing

All types

All types

Types	Length	Width	Rail thickness	Maintain electrical functions	Item no.	Quantity	SSU
SLZ L 100 A4	3000 mm	100 mm	3 mm	no	7098082	m	3 m
SLZ L 200 A4	3000 mm	200 mm	3 mm	no	7098086	m	3 m
SLZ L 300 A4	3000 mm	300 mm	3 mm	no	7098088	m	3 m
SLZ L 400 A4	3000 mm	400 mm	3 mm	no	7098090	m	3 m
SLZ L 500 A4	3000 mm	500 mm	3 mm	no	7098092	m	3 m
SLZ L 600 A4	3000 mm	600 mm	3 mm	no	7098094	m	3 m
