CombiController V25

Item no. 5097438 | EAN 4012195505273

Item no. / Types	5097438 / V25-B+C 3

Pole version	3

Maximum continuous voltage AC	280 V

Protection rating	IP20

Product description

Product description

Combination arrester consisting of lightning current and surge arrester type 1+2

• Complete unit consisting of cover and base, pre-mounted and ready for connection

• Plug-in arrester with dynamic cut-off unit

• With visual function display

• Protection level < 0,9 kV

• Encapsulated, non-extinguishing zinc oxide varistor arrester for use in standard distributor housings

• Labelled connections

• Special version with two earthing terminals and earthing strap

Application example: Buildings with open-wire power supply or for setting up lightning protection equipotential bonding in residential buildings.
* Complete = Upper part and base

Technical data

Technical data

Blow-out	no
Conductor cross-section, rigid (single-wire/multiwire), max.	35 mm²
Conductor cross-section, rigid (single-wire/multiwire), min.	2,5 mm²
Dimension	280V
Lightning protection zone LPZ	0→2
Lightning surge current (10/350 μs)	25 kA
Max. mains-side overcurrent protection	160
Maximum back-up fuse	160 A
Maximum continuous voltage AC	280 V
Maximum discharge current (8/20 μs)	50 kA
Nominal discharge current (8/20 µs)	30 kA

Operating temperature, max.	80 °C
Operating temperature, min.	-40 °C
Pole version	3
Protection rating	IP20
Response time	<25 ns
Signalling on device	Visual
SPD to EN 61643-11	Type 1+2
SPD to IEC 61643-1	Class I+II
TN network form	yes
TN-C network form	yes
