Cover for 90° vertical bend 85, falling, FS
Item no. 7131002 | EAN 4012195712015
- Product description
-
Product descriptionCover for falling vertical bends of side height 85 mm.
-
- Technical data
-
Technical data
Bend (angle) 90° Change of direction Vertical, falling Colour zinc Dimension B400mm Dimension B 400 mm Fastening type Sash lock Height 85 mm Hinged no Maintain electrical functions no Material Steel Plate thickness 0,03 in Plate thickness 0,75 mm Rustproof steel, pickled no Suitable for cable ladder no Suitable for cable tray yes Suitable for mesh cable tray no Surface Strip galvanized Width 400 mm Width 16 in - All types
- Downloads
-
Data sheet DBV 85 400 F FS / 7131002 , 0.17MB , pdfCatalogue Kabeltragsysteme , 45.23MB , pdfEU declaration of conformity DBV 85 400 F FS / 7131002 , 0.10MB , pdfREACH Declaration of conformity DBV 85 400 F FS / 7131002 , 0.12MB , pdfRoHS Declaration of conformity DBV 85 400 F FS / 7131002 , 0.12MB , pdfMounting instructions General information on the mounting , 2.61MB , pdf
