- Product description
-
Product description
These push-fit clips are used when installing cables and pipes on walls and ceilings and when running flexible pipes on concrete and in the screed. The double push-fit clips can be used instead of nail clips in concrete and aerated concrete. The advantage of the push-fit clips is that they only have to be pushed into the drilled hole. Anchors and bolts are not needed.
- Technical data
-
Technical data
Breaking load for concrete B25 120 N Clamping range D, max. 25 mm Clamping range D, min. 12 mm Colour Light grey; RAL 7035 Dimension 12-25mm Drill hole depth 40 mm Drill hole diameter, min. 6 mm Fastening type Plug fastening Halogen-free yes Material Polyamide Number of cables/pipes 2 Version for Two-lobe - All types
- Downloads
-
Data sheet 1974 2X12-25 / 2197863 , 0.18MB , pdfDeclaration of conformity 1974 2X12-25 / 2197863 , 0.06MB , pdfREACH Declaration of conformity 1974 2X12-25 / 2197863 , 0.12MB , pdfRoHS Declaration of conformity 1974 2X12-25 / 2197863 , 0.12MB , pdf
