Earthing terminal for fastening on earthing strap

Item no. 5040507 | EAN 4012195385936

5040507 / 928
Round conductor
Product description

Product description

• For use in bathtubs or shower tubs etc.

• Connection option: conductors to 16 mm²

• Clamping element with threaded connection M6, 1 hexagonal nut M6,

1 serrated dimension washer and 1 cylinder bolt M5 x 8

• Clamping element, nut and screws from copper-plated brass

• Serrated washer from stainless steel; 2 washers from galvanised steel
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Dimension 1/2"
Material Brass
Suitable for Round conductor
Surface Nickel-plated
All types

All types

Types Suitable for Item no. Quantity SSU
928 Round conductor 5040507
10 piece
Downloads

Download

Download

REACH Declaration of conformity 928 / 5040507 , 0.13MB , pdf
RoHS Declaration of conformity 928 / 5040507 , 0.13MB , pdf
