Inlay plate A2

Item no. 6103614 | EAN 4012195037354

3000 mm
Product description

Product description

Insert plate for use in cable ladders.
For the fastening in wide span cable ladders use truss-head bolts with the combination nut of type FR SB 6x30.
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • UKCA declaration of conformity
  • Wide span cable ladder, side height 110 mm
Technical data

Technical data

Dimension 200x3000
Dimension B 200 mm
Height 45 mm
Length 3000 mm
Material Stainless steel
Material thickness 1 mm
Surface Bright, treated
Width 200 mm
All types

All types

Types Length Width Item no. Quantity SSU
ELB-L20 A2 3000 mm 200 mm 6103614
21 m
ELB-L30 A2 3000 mm 300 mm 6103618
3 m
ELB-L40 A2 3000 mm 400 mm 6103622
18 m
ELB-L50 A2 3000 mm 500 mm 6103626
27 m
ELB-L60 A2 3000 mm 600 mm 6103630
42 m
Accessories

Mounting accessories

Products Types Item no. Quantity SSU
Truss-head bolt with flange nut F Truss-head bolt with flange nut F FRSB 6x30 F 6406907
100 piece
