isCon® connection elements set ASE, testable for isFang IN

Item no. 5408082 | EAN 4012196876600

5408082 / isCon ASE 23 IN
28 mm
23 mm
Product description

Product description

• For the isCon® Pro+ and Premium conductor
• Set consisting of 2 testable connection elements
• Connection and routing of the cable in the insulated air-termination mast
• For function and state determination with integrated ASE technology (Adaptive Switching Element)
• For comprehensive repeat testing according to VDE 0185-305-3 (IEC/EN 62305-3)
• Screw-on termination
• Testable with the simplest insulation measuring devices (≥ 1 kV DC)
• Can be used in all lightning protection classes
• For highest system availability - no switch-off, dismantling or testing with
dangerous pulse voltages
• QR code to open the test report
• Incl. heat-shrinkable hose and Allen key
  • Lightning current-tested
Technical data

Technical data

Clamping range, max. 23 mm
Connection Round conductor
Dimension 23mm
Dimension d min. 28 mm
Fit 23 mm
Material Stainless steel
Type of fastening screw Miscellaneous
All types

All types

Types Dimension d min. Fit Item no. Quantity SSU
isCon ASE 23 IN 28 mm 23 mm 5408082
1 piece
Accessories

Mounting accessories

Products Types Item no. Quantity SSU
Stripping tool for isCon® conductor Stripping tool for isCon® conductor isCon stripper 2 5408013
1 piece
Downloads

isCon ASE 23 IN / 5408082
Download
