Product description
Closed entry nipple with perforation membrane for cable diameters 7‒13 mm. Ideal for simple cable routing in housings or through thin sheet metal.
Required hole diameter 18.5‒19 mm, wall thickness max. 1.8 mm.
- Technical data
-
Technical data
Colour Black Dimension Ø7-13mm Dimension t 1,8 mm Flame-resistant acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C for diameter, max. 13 mm for diameter, min. 7 mm for wall thickness, max. 1,8 for wall thickness, min. 1,8 Halogen-free yes Material Ethylene vinyl acetate Nominal size PG 11 Size PG 11 Version for Closed - All types
- Downloads
-
Data sheet 89 SW / 2012146 , 0.19MB , pdfREACH Declaration of conformity 89 SW / 2012146 , 0.12MB , pdfRoHS Declaration of conformity 89 SW / 2012146 , 0.12MB , pdf
