Nipple 89/RK 12 | 16 | PG 13,5
morepic-1 morepic-2

Nipple 89/RK

Item no. 2012049 | EAN 4012195156130

2012049 / 89 ROE 12-16
12 mm
16 mm
PG 13,5
Product description
Product description
Closed entry nipple with perforation membrane for cable diameters 12–16 mm. Ideal for simple cable routing in housings or through thin sheet metal.

Required hole diameter 18.5‒19 mm, wall thickness max. 3 mm.
  • Halogen-free; without chlorine, fluorine and bromine
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Colour Light grey; RAL 7035
Dimension Ø12-16mm
Dimension t 3 mm
Flame-resistant acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
for diameter, max. 16 mm
for diameter, min. 12 mm
for wall thickness, max. 3
Halogen-free yes
Material Polyethylene, low density
Nominal diameter 19 mm
Nominal size PG 13,5
Protection rating IP54
Size PG 13,5
Version for Cuttable
All types

All types

Types for diameter, min. for diameter, max. Size Item no. Quantity SSU
89 ROE 12-16 12 mm 16 mm PG 13,5 2012049
100 piece
