Rod holder, 16 mm

Item no. 5412609 | EAN 4012195429616

5412609 / 113 Z-16
Rd 16 mm
Product description

Product description

• For air-termination and earth entry rods Rd 16
• Installed with crossbar and hexagonal bolts M6 x 16
• With female thread M8 or through hole Ø 7 mm

Technical data

Technical data

Dimension 16mm
Fit Rd 16 mm
Holder fastening type Drill hole with M thread
Material Die-cast zinc
Material of the base Die-cast zinc
Material of the crossbar Die-cast zinc
Rod fastening type With screw clip
Surface galvanised
Thread metric 8
All types

All types

Types Fit Item no. Quantity SSU
113 Z-16 Rd 16 mm 5412609
10 piece
