Snap clip

Item no. 2148021 | EAN 4012195844518

6 mm
Light grey; RAL 7035
Product description

Product description

With moulded-on push-fit plug for rapid mounting in concrete walls and masonry.
Push plug into hole until the clip makes contact with the surface. When the pipe is pressed into the clip, the arms of the clip grip it.
  • Halogen-free; without chlorine, fluorine and bromine
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Breaking load for concrete B25 90 N
Clamping range D, max. 15 mm
Clamping range D, min. 12 mm
Colour Light grey; RAL 7035
Dimension 12-15mm
Drill hole depth 40 mm
Drill hole diameter, min. 6 mm
Fastening type Plug fastening
Halogen-free yes
Material Polyamide
Number of cables/pipes 1
Version for Closed
All types

All types

Types Drill hole diameter, min. Breaking load for concrete B25 Clamping range D, min. Clamping range D, max. Colour Item no. Quantity SSU
1975 12-15 6 mm 90 N 12 mm 15 mm Light grey; RAL 7035 2148021
100 piece
1975 16-19 6 mm 150 N 16 mm 19 mm Light grey; RAL 7035 2148048
100 piece
1975 19-22 6 mm 90 N 19 mm 22.5 mm Light grey; RAL 7035 2148056
100 piece
