Strain relief clip 7909

Item no. 1443011 | EAN 4012195135616

1443011 / 7909 6 G
6
1 mm
Product description
Product description
Fastening clip for strain relief of cables
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Clamping range D, max. 6 mm
Clamping range D, min. 6 mm
CO₂ Footprint (GWP) Cradle-to-Gate 0,0071 kg CO₂e / 1 Piece
Dimension 6mm
Distance to the wall no
Fastening type Screw hole
For diameter 6
Halogen-free yes
Material Steel
Material thickness 1 mm
Nominal diameter 6 mm
Number of cables/pipes 1
Plastic-covered no
Suitable in fire protection area no
Surface Electrogalvanized
UV-resistant yes
Version for Two-lobe
All types

All types

Types For diameter Material thickness Item no. Quantity SSU
7909 6 G 6 1 mm 1443011
100 piece
