Surge protection module 230 V
Item no. 5092451 | EAN 4012195080886
- Product description
-
Product descriptionSurge protection module type 3 to DIN EN 61643-11 for 230 V power grids.
• With audible defect signal
• With low construction height
• Halogen-free plastic (UL 94 V-0)
• Y circuit
Application: Universally applicable for all installation systems.
-
- Technical data
-
Technical data
Cable type for surge protection devices Power cable AV Combined voltage protection level [L-PE] 1500 kV CO₂ Footprint (GWP) Cradle-to-Gate 0,0239 kg CO₂e / 1 Piece Dimension 255V Installation type Miscellaneous Lightning protection zone LPZ 2→3 Max. mains-side overcurrent protection 16 Maximum back-up fuse 16 A Maximum continuous voltage AC 255 V Maximum discharge current (8/20 μs) 6 kA Network form Other Nominal discharge current (8/20 µs) 3 kA Nominal voltage AC (50/60 Hz) 230 V OBO_Nominal load current (input/output terminal) 16 A Operating temperature, max. 60 °C Operating temperature, min. -15 °C Pole version Other Protection level wire-earth 1500 V Protection level [L-N] ≤1500 Response time <25 ns Signalling on device Acoustic SPD to EN 61643-11 Type 3 SPD to IEC 61643-1 Class III Version for Acoustic operating display - All types
- Downloads
-
Data sheet ÜSM-A / 5092451 , 0.23MB , pdfEU declaration of conformity ÜSM-A / 5092451 , 0.11MB , pdfREACH Declaration of conformity ÜSM-A / 5092451 , 0.12MB , pdfRoHS Declaration of conformity ÜSM-A / 5092451 , 0.12MB , pdfSelection aid Selection aid, surge protection , 2.00MB , pdfTechnical information Technical information, ÜSM-A , 0.06MB , pdf
