Underfloor test box with integrated separation point

Item no. 5106003 | EAN 4012196089512

5106003 / 5700 SP
RD 8-10 x FL 30-40 mm
227x155x115
Product description
Product description
• Without base

• Cast iron, painted black

• With built-in cut-off unit for round conductors Rd 8-10 and flat conductors to FL 40

• To VDE 0185-561-5 (IEC 62561-5) suitable for heavy loads (up to 40 kN/4.0 t)


  • Lightning current-tested
Technical data

Technical data

Colour Black
CO₂ Footprint (GWP) Cradle-to-Gate 15,373 kg CO₂e / 1 Piece
Dimension 227x155x115
Fit RD 8-10 x FL 30-40 mm
Material Cast iron
All types

All types

Types Fit Dimension Item no. Quantity SSU
5700 SP RD 8-10 x FL 30-40 mm 227x155x115 5106003
1 piece
